China Plastic Valves Factory Pntek Compact Ball Valve PVC Pressure Reducing Valve pabrika at mga tagagawa |Pntek

Plastic Valves Factory Pntek Compact Ball Valve PVC Pressure Reducing Valve

Maikling Paglalarawan:

$0.10 - $8.00/ Piraso|2000 Piraso/Piraso(Min. Order)
Sukat:
1/2in3/4IN1in1 1/4in1 1/2in2in2 1/2in3in4in5in6in8in
Materyal:
PlasticGoma
Presyon:
Katamtamang Presyon8-16kgs
Mga sample:
5in , Plastic , 8-16kgs
$0.20/Piraso |1 piraso (Min. Order) |Bumili ng Mga Sample
Lead Time:
Dami(Mga Piraso) 1 - 20 >20
Est.Oras(araw) 10 Upang mapag-usapan
Pag-customize:
Customized na logo(Min. Order: 2000 Pieces)
Customized na packaging(Min. Order: 2000 Pieces)
Pagpapadala:
Suportahan ang kargamento sa Dagat

Uri::MGA balbula ng bola

Naka-customize na suporta::OEM, ODM

Temperatura ng Media::Katamtamang Temperatura, Normal Temperatura

Magpadala ng email sa amin

Detalye ng Produkto

FAQ

Mga Tag ng Produkto

Alamat at pisikal na mapa

singleproducimg

Materyal ng sangkap

pagtutukoy ng materyal

HINDI.	Bahagi	materyal	QTY
1	KATAWAN	UPVC,CPVC	1
2	STEM O-Ring	EPDM,FPM(NBR)	1
3	STEM	UPVC,CPVC	1
4	BOLA	UPVC,CPVC	1
5	SEAT SEAL	TPE,TPVC,TPO	2
6	TAKIP	PVC, ABS	1
7	HAWAKAN	PVC, ABS	1
8	TULONG	SS304, BAKAL	1

Talaan ng paghahambing ng parameter ng laki ng modelo

DIMENSYON												Yunit
MODELO	DN		15	20	25	32	40	50	65	80	100
	SIZE		1/2"	3/4"	1"	1-1/4"	1-1/2"	2"	2-1/2"	3"	4"	pulgada
	thd./in	NPT	14	14	11.5	11.5	11.5	11.5	8	8	8	mm
	thd./in	BSPT	14	14	11	11	11	11	11	11	11	mm
	JIS	I	20	20	24	26	30	31	45	48	53	mm
		d1	22.3	26.3	32.33	38.43	48.46	60.56	76.6	89.6	114.7	mm
		d2	21.7	25.7	31.67	37.57	47.54	59.44	75.87	88.83	113.98	mm
	ANSI	I	18	20	24	26	30	31	45	48	53	mm
		d1	21.54	26.87	33.65	42.42	48.56	60.63	73.38	89.31	114.76	mm
		d2	21.23	26.57	33.27	42.04	48.11	60.17	72.85	88.7	114.07	mm
	DIN	I	18	20	24	26	30	31	45	48	53	mm
		d1	20.3	25.3	32.3	40.3	50.3	63.3	75.3	90.3	110.4	mm
		d2	20	25	32	40	50	63	75	90	110	mm
	d		15	19	24	30	34	45	55	70	85	mm
	H		37	55	66	73	81	91	99	121	134	mm
	A		68	80	94	100	110	136	170	210	236	mm
	L		77	91	103	111	123	146	178	210	255	mm
	D		32	37.5	44	52	60	74	93	110	135	mm
